A5

A5

A5 is best suited for CNC machines, swiss machines and grinding machines that are running with high speeds and high coolant pressures. It can also be adapted to fit the requirements of different applications. This makes it our smartest filter unit yet.

  • Low maintenance costs thanks to long lasting filter cassettes and EcoDrive
  • Improves the environment inside as well as outside of your workshop thanks to the ”Catch & Release” function.
  • Versatile placement thanks to double air inlets and oil outlets. Twice as convenient!

No More Smoke

The fan adapts to your needs. Energy smart and health safe!

1.5 barrels of oil

No more slippery floors and dangerous smoke. Only 1 teaspoon per year remains, And clean air!

Clean Air Always

The HEPA H13 filter guarantees clean air – always. Only the best is good enough!

8760 running hours

Four filter stages capture all particles – giving you 1 year of maintenance free operation.

A5

Versatile Use

A5 is best suited for CNC machines, swiss machines and grinding machines that are running with high speeds and high coolant pressures. Its small size makes A5 ideal for machine mounting, but of course you can also put it on a floor stand or hang it from your wall or ceiling if that is what you prefer. This new unit is the perfect match for a machine with an inner space of up to 2.5 m3/89 ft3. A5 can also be adapted to fit the requirements of different applications. This makes it our smartest filter unit yet.

Unique Function

A5 has four unique filter stages that we adapt to your machine. Each one captures millions of particles. The first three are self-draining filter cassettes from Absolent. These have the ability to drain the captured oil so that it can be reused in the machine instead of polluting the premises. This is what we call our Catch & Release principle. The fourth filter us a HEPA H13. Thanks to this we can ensure clean air during the entire operating time. It filters at least 99.97% of all particles. In other words, it is a filter for your safety.

Acontrol

A5 comes with Acontrol. A handheld, electronic device with a seven inch color screen that gives you new opportunities to manage, control and monitor your filter unit. The Acontrol has information about the pressure drop in each filter stage, running hours, fan speed and much more. You can adjust all settings right from the hand unit. It has never been so easy to clean the air from and around your machines.

Technical InformationMetricImperial
Height850 mm33.5 in
Width560 mm22 in
Depth665 mm26.2 in
Weight, dry filter cassettes80 kg175 lbs
Max. Airflow500 m³/h300 cfm
Motor Output360 W0.5 hp
Inlet DuctØ 125 mmØ 4.9 in
Typical Values for this FIlter Unit
Oil Amount, In1.5 barrels/yr1.5 barrels/yr
Oil Amount, Out1 tsp/yr1 tsp/yr

*Inlet duct not included for the US market
